Efficient Outdoor Intelligent Ring Main Unit Box-Type Switchgear for Outdoor Use

Customization:	Available
Certification:	VDE, CCC, ISO9001
Shell Material:	Steel Plate

i

Basic Information

Model NO.	Box-type switchgear	Voltage Level	High Voltage
Installation	Removable	Structure	Floorstanding
Current	AC	Rated Voltage	12kv, 24kv
Rated Frequency	50Hz/60Hz	Rated Current of Main Busbar	630A
Short-Circuit Breaking	20ka, 25ka, 31.5ka	Origin	China
HS Code	8502110000	Production Capacity	200 Piece/Month

P

Product Description

The box-type switchgear (pre-assembled outdoor switchgear) is a complete set of power distribution equipment that integrates 10kV/24kV high-voltage switchgear, protection devices, metering devices, etc. into an outdoor box. It complies with standards such as GB 17467 and IEC 62271-200. The product adopts modular and prefabricated design, integrating core components such as ring main units / air-insulated cabinets, cable terminals, and lightning arresters. It is mainly used in urban distribution networks, industrial parks, and residential areas for receiving and distributing electrical energy.

Structural Composition

• Outdoor Enclosure: Made of high-quality steel or stainless steel plates with anti-corrosion spraying. Protection level IP34, featuring rainproof, dustproof, and dew-proof capabilities. Equipped with lighting, dehumidification, and temperature control.

• High-voltage Switchgear: Core unit adopts XGN15-12 ring main unit, SF6 gas-filled cabinet, or environmentally friendly gas-filled cabinet. Supports manual/electric operation with complete mechanical interlocks.

• Auxiliary Systems: Sufficient space for cable installation with fixing brackets. Configured with microcomputer protection devices, fault indicators, and communication interfaces for remote control.

A

Product Advantages

Prefabricated Integrated Design: Assembled and debugged in the factory. Shortens installation time by more than 80% compared to traditional civil construction.
Strong Environmental Adaptability: IP34 protection level, adaptable to extreme environments from -40℃ to +70℃. Ideal for coastal and high-altitude areas.
Modular & Flexible: Functions such as incoming/outgoing lines, metering, and PT can be freely combined to meet specific distribution network architectures.

Application Fields

Urban distribution network ring network power supply
Residential communities and commercial complexes
Industrial parks, factories, mines, and oilfields
New energy power stations (photovoltaic, wind power)

Technical Specification

Parameter	Specification Details
Rated Voltage	12kV, 24kV
Rated Frequency	50Hz / 60Hz
Rated Current of Main Busbar	630A
Rated Short-circuit Breaking Current	20kA, 25kA, 31.5kA
Protection Class	IP34 (Outdoor Enclosure)
Operation Mode	Manual / Electric / Automatic
